A few years ago, the OpenZiti project developed and published two client tools to make ssh and scp available over an OpenZiti overlay network without requiring the sshd port to be exposed to the internet. If interested, read the original posts about zssh and zscp. Continuing with the belief that security-related code should be open source and auditable, the project is available on GitHub.
The OpenZiti project provides SDKs that developers can use to create secure connections. The zssh
client demonstrates that adopting an OpenZiti SDK into an application is no harder than developing any application that uses traditional IP-based, underlay connectivity.
Secondly, though uncommon, there are still vulnerabilities found in ssh
. Just this year (2024) RegreSSHion was discovered and was given a staggering CVSS score of 9.8. Scores greater than 9 are generally deemed a "patch this as soon as possible" type of CVE. Yes, today's ssh
clients are incredibly robust, but if it's easy to remove a substantial portion of attackers from attacking a service by using a zero trust overlay network like OpenZiti, why wouldn't you?
Using *ssh.Client
The go ecosystem provides extended packages from the golang.org/x/*
modules. One of these modules is golang.org/x/crypto
. Within this module, there is an ssh
package that provides everything needed to make a functional ssh client. In there is ssh.Client
, the main thing you'll interact with. This struct, along with ssh.NewClientConn
and the Golang standard library, provides all the functionality needed to create a simple ssh client.
Shown below is all the code needed to make a very contrived ssh example. Any errors are ignored, and all values are hard-coded or expected as arguments to the program to keep the example small. In total, there are fewer than 30 total lines. Hopefully, the example is straightforward enough to understand.
package main
import (
"golang.org/x/crypto/ssh"
"os"
)
func main() {
key, _ := os.ReadFile(os.Args[1])
signer, _ := ssh.ParsePrivateKey(key)
config := &ssh.ClientConfig{
User: "ubuntu",
Auth: []ssh.AuthMethod{ssh.PublicKeys(signer)},
HostKeyCallback: ssh.InsecureIgnoreHostKey(),
}
sshClient, _ := ssh.Dial("tcp", os.Args[2], config)
defer sshClient.Close()
session, _ := sshClient.NewSession()
defer session.Close()
session.RequestPty("xterm", 80, 40, ssh.TerminalModes{})
session.Stdout = os.Stdout
session.Stderr = os.Stderr
session.Stdin = os.Stdin
session.Shell()
session.Wait()
}
Try it out! That's really all there is to it. You'll be able to ssh to any machine that uses key-based authentication. Although it's not a robust example, it demonstrates the overall idea and shows off how amazing the go ecosystem can be. Note that ssh.InsecureIgnoreHostKey
is used for the HostKeyCallback
, to keep the example short. See zssh
's implementation if interested
Layering in Zero Trust Connectivity
The Golang standard library is well thought out. The abstractions in place make it amazing for building applications embedding zero trust. Adapting an application that uses normal IP-based connectivity (like the ssh example shown above that uses "tcp") to use an OpenZiti SDK is generally straightforward. From the example above, a single line needs to be changed: the line that creates the ssh.Client
. This line:
sshClient, _ := ssh.Dial("tcp", host, config)
Creating the sshClient
needs to be adapted away from using IP-based underlay networking. Instead of "tcp" and "remote-machine-name:22", it needs to use a zero trust connection provided by the OpenZiti Golang SDK. Below is a simplified function that uses an OpenZiti identity file to create an OpenZiti context and dial an OpenZiti service, creating a Golang net.Conn
that can be used to create an ssh.Client
. Again, the example omits error handling and robustness for simplicity's sake, and looks like this:
func obtainZitiConn() net.Conn {
cfg, _ := ziti.NewConfigFromFile(os.Args[3])
ctx, _ := ziti.NewContext(cfg)
dialOptions := &ziti.DialOptions{
Identity: host,
}
c, _ := ctx.DialWithOptions("zsshSvc", dialOptions)
return c
}
With the IP-based underlay net.Conn
connection replaced with a zero trust connection, an ssh.Client
can be created by replacing the call to ssh.Dial
, and instead using a call to ssh.NewClientConn
combined with a call to ssh.NewClient
. With the ssh.Dial
line adapted, it looks like this:
//adapted sshClient, _ := ssh.Dial("tcp", host, config)
c, chans, reqs, _ := ssh.NewClientConn(obtainZitiConn(), "", config)
sshClient := ssh.NewClient(c, chans, reqs)
Everything else in the example remains identical; these are the only lines that need to change! The full source for zssh
is available on GitHub at https://github.com/openziti-test-kitchen/zssh. You'll find the examples shown above in that repo as individual, compilable go files available in the example
folder.
If you're interested in zssh
, the OpenZiti project and zero trust in general, check out the next article. It focuses on using zssh
and using OpenZiti's OIDC-based authentication mechanisms and uses Keycloak for federated authentication to GitHub or Google.
